Product Specifications
ApplicationHVACDimensions (in.)2.8 in. high x 3.7 in. wide x 2.7 in. deepDimensions (mm)70 mm high x 94 mm wide x 68 mm deepIncludesFlexible conduit adapterUsed WithVC Series Valves, 1000 Series 2-way and 6000 Series 3-wayWeight (lb)0.75 lbWeight (kg)0.34 kgMaterialsPlastic housingItem TypeProductMountingDirect CoupledFrequency60 HzApprovals, Underwriters Laboratories Inc.Listed 94-5VApprovals, Canadian Standards AssociationCSA Certified: LR1322-367Electrical ConnectionsPlenum-rated cableOperating Humidity Range (% RH)5 to 95% RH, non-condensingSupply Voltage24 VacPower ConsumptionDriving-- 6 VAShipping and Storage Temperature Range (F)-40 F to +150 FShipping and Storage Temperature Range (C)-40 C to +65 CApprovals, CE89/336/ECC, 73/23/EECAmbient Temperature Range (C)0 C to 65 CAmbient Temperature Range (F)32 F to 150 FElectrical Connections (in.)5 ft.Electrical Connections (mm)1.5 mEnvironmental, Electrical or Ingress Protection RatingDouble Insulated, IP40Internal Auxiliary Switch0Fluid Temperature (C)95 CFluid Temperature (F)203 FActuator TypeValveControl SignalTwo position; SPSTFail Safe ModeStays in placeStroke (in.)0.4 in.Stroke (mm)10 mmCableMolded strain relief, conduit clampTiming, NominalDriving @ 60 Hz-- 6 secMaximum Differential Pressure Ratings (Close-off) (psi)60 psidMaximum Differential Pressure Ratings (Close-off) (kPa)400 kPaShaft Adapter TypeSelf-alignmentManual operationLever
